The Devor 16 is a high performance horn loaded infrabass and subwoofer system with two very powerful 21” drivers.

Horn loading

The horn loading mechanism enables sensitivity, impulse response, and an impressive distortion level. The horn design provides high quality audio reproduction down to 16Hz. Devor 16 provides a low frequency response with very low distortion and a fast impulse response, where sound quality is combined with a frequency response that extends to infrasound.

Sub cardioid - Low distortion

The Devor 16 has a close to sub cardioid dispersion pattern all through its intended bandwidth – even at infrabass frequencies. This allows the sound pressure to be directed towards the audience, and minimizes the need for acoustical treatment of the room, as less energy is reflected off surrounding surfaces.

Mechanically balanced design

The Devor 16 is designed with dual 21’’ drivers, working mechanically in a push push configuration to feed the horn. This cancels out the movement exercised on the cabinet by each driver and minimizes distortion from the cabinet. This also contributes to the audience perceiving the bass signal through the air, along with rest of the music instead of out of time through the floor.

High SPL to infrasound

The Devor 16 is appropriate for a broad range of applications. From large outdoor applications to concert halls, clubs, cinemas, and auditoriums. It can be used as a bass effect generator to replicate thunderstorms and earthquakes and war simulation in military training. For very high-end applications, like bass extension in studio, HiFi, and home cinema setups, the Devor 16 provides the ultimate experience.

Specification

Configurations: Active 2-way
Frequency response ±3dB: 16 Hz - 80 Hz
Max. cont. SPL (1m, 2Pi): 140 dB
Nominal impedance front/rear: 8 O
Power handling capacity (cont./ peak): 3600 W / 7200 W
Connections: Speakon 4 pole

Height: 1490 mm / 58.7 in
Width: 1490 mm / 58.7 in
Depth: 600 mm / 23.6 in
Weight: 200 kg / 441,0 lb
