Technical Specifications

• Custom edge terminated, all-brass vintage CK12-style capsule

• Custom TAB-Funkenwerk (AMI) USA Output Transformer

• Premium 12AY7 vacuum tube

• Premium Capacitors

• Polar Patterns: 9 Patterns - Cardioid, Omnidirectional, Figure-8, + 6 additional mixed patterns

• Max SPL: 149dB

• Frequency Response: 30Hz-20kHz

• Output Impedance: 200 ohms

• Signal-to-Noise Ratio: 73dB

• EIN / Self-noise: 32dBA

• Total Weight: 17 lbs, Mic only: 2lbs 7oz

• Mic Dimensions: 11 ?” x 2” (29.5cm x 5cm)

• Included Accessories: Custom tweed carrying case, external IEC grounded PSU, IEC power cable, premium Gotham 5 meter 7-pin tube microphone cable, wood microphone box, shockmount
