Technical Specifications

• Gold Sputtered, Large Diaphragm, Single Backplate, K47 Style Capsule

• Custom TAB-Funkenwerk (AMI) USA Output Transformer

• Premium Fairchild Transistors

• Wima and Polystyrene Capacitors

• Polar Pattern: Cardioid

• Max SPL: 137dB, 147dB with 10dB pad engaged

• Frequency Response: 20Hz-19kHz

• Output Impedance: 150 ohms

• Rated Load Impedance: >1kOhms

• Pads and Filters: -10dB pad, 140 Hz low-cut filter

• Signal-to-Noise Ratio (+ weighted): 69 dB, 76 dB-A

• EIN / Self-noise (+ weighted): 25dB, 18 dB-A

• Total Weight: 3.5lbs, Mic only: 2lbs

• Mic Dimensions: 8” x 2.75” (20.3cm x 7cm)

• Included Accessories: premium wood box & hard mount
