AMS NEVE 1081R-AIR Module
The Ultimate Preamp for Detailed Ambient Recording
Designed in collaboration between George Martin, Geoff Emerick and Rupert Neve, the AIR preamp became an essential component of the Air Montserrat consoles. Renowned for its transparency, this analogue technology is enhanced in the AIR module (compatible with the 1081R rack) with complete digital remote control.
The Air Montserrat console pioneered digital control technology; the AIR module builds upon the legacy of the remote preamps from this legendary console. The AIR module can be controlled from an 88R console or a connected Mac/PC. Taking advantage of this system by placing the 1081R rack in the live room keeps mic lines short, improving signal degradation at the crucial sound capture stage.
Audio Performance
- Input Impedance: 1.2k Ohm, @1kHz
- Gain: +20 to +70 in 5dB steps
- Distortion: not more than 0.025% for 20dBm output from 20Hz to 20kHz @ 60dB gain
- Noise: (22Hz to 22kHz bandwidth) EIN better than -125dB @ 60dB gain
- Microphone Maximum Input Level with ‘pad’ in: +24dB
- Max Output: +26dBu into 600 Ohms
- Output impedance: 50 Ohms +/-5%@1kHz, balanced
Rack Specification (fully populated)
- Power: < 40w, 100-240v auto sensing, 47-63Hz, 1.6A Anti Surge Fuse.
- Mechanical: 4U x 19? 260mm deep.
- Audio Connections: 12 balanced circuits on a 56-way panel mounted female Varicon.
- Control Connections: 2 x 9 Pin D Type ‘Male’ input and ‘Female’ output, RS485 format (adaptors required for serial RS232).
